Fully-sealed colloidal mill (horizontal)
  • This product has utility model, the appearance of a number of patents, its compact structure, form new, environmental protection, energy conservation, stable performance.
  • This product implementation of the national standard GB / T 14466 and enterprise standards Q/WSS01-2004, pioneered by China.
  • This product body parts and materials contact parts are stainless steel materials. A3 paint or stainless steel rack.
  • Horizontal distribution of the products motor attached and the body structure with the axis of rotation. And configure a hopper, and the circulatory system.
  • The new product design, simple operation, easy installation and maintenance, small size, high efficiency characteristics.
  • This product ultrafine particles for the wet grinding, crushing, emulsion, mixing, dispersion, heterogeneity, stirring, and so efficient function.
  • Apply to all types of media emulsion liquid or paste material handling viscous material density ≥ 10000% parked medium.
  • With the customer on different materials processing acidity, alkalinity, stiffness of the nature of special requirements, such as customized production.
  • Can be a substitute and better than stone, sanding machine, ball mill, milk-absorbed, emulsifying machine, three-roll machine, broken up for work.
  • This product is a fully closed hopper (container) structure, for flavor, methanol, ethanol and other volatile explosive or flammable materials processing.

Technical parameter a:

Main technical parameter

Degree of emulsification(um)

Change according to nature of the supplies
(T/h)

Mill Diameter
(mm)

Import diameter
(mm)

Export diameter
(mm)

Cooling circulation external diameter
(mm)

Main rotational speed
(r/min)

Power
(Kw)

External dimension
(Long×Wide ×High)mm

Weight
(Kg)

Type

JM-WBF500

2-50

10-50

Ø400

Ø125

Ø80

Ø12

1450-2900

45-200

1200×600×1300

685

JM-WBF400

2-50

10-40

Ø400

Ø125

Ø80

Ø12

1450-2900

45-200

1200×600×1300

580

JM-WBF350

2-50

6-35

Ø350

Ø125

Ø80

Ø12

2900

45

1200×600×1300

550

JM-WBF320

2-50

5-30

Ø320

Ø125

Ø80

Ø12

2900

37

1100×550×1300

500

JM-WBF320a

2-50

5-30

Ø320

Ø125

Ø80

Ø12

2900

45

1100×600×1300

550

JM-WBF250a

2-50

2-20

Ø250

Ø125

Ø60

Ø12

2900

30

1100×450×1300

400

JM-WBF250b

2-50

2-20

Ø250

Ø125

Ø60

Ø12

2900

37

1100×450×1300

425

JM-WBF200a

2-50

2-10

Ø200

Ø100

Ø50

Ø12

2900

15

750×450×1250

235

JM-WBF200b

2-50

2-10

Ø200

Ø100

Ø50

Ø12

2900

22

750×450×1250

250

JM-WBF200c

2-50

2-12

Ø200

Ø100

Ø50

Ø12

2900

30

750×450×1250

310

JM-WBF180a

2-50

2-6

Ø180

Ø90

Ø40

Ø12

2900

11

1000×450×1250

215

JM-WBF180b

2-50

2-6

Ø180

Ø90

Ø40

Ø12

2900

15

1000×450×1250

240

JM-WBF180c

2-50

2-7

Ø180

Ø90

Ø40

Ø12

2900

22

1000×450×1250

258

JM-WBF140a

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

7.5

780×370×1200

187

JM-WBF140b

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

11

780×370×1200

192

JM-WBF140c

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

15

780×370×1200

225

JM-WBF130

2-50

0.7-3

Ø130

Ø65

Ø30

Ø12

2900

7.5

750×360×1170

180

JM-WBF120

2-50

0.7-2.5

Ø120

Ø65

Ø30

Ø12

2900

5.5

750×360×1150

170

JM-WBF100

2-50

0.5-2

Ø100

Ø65

Ø30

Ø12

2900

5.5

740×350×1150

158

JM-WBF90

2-50

0.5-1.5

Ø80

Ø47

Ø20

Ø12

2900

4

730×380×1100

110

JM-WBF80

2-50

0.5-1

Ø80

Ø47

Ø20

Ø12

2900

4

730×380×1100

102

JM-WBF65

2-50

0.2-0.5

Ø65

Ø47

Ø20

Ø8

2900

2.2

700×350×980

95

Technical parameter b:

Main technical parameter

Degree of emulsification(um)

Change according to nature of the supplies
(T/h)

Mill Diameter
(mm)

Import diameter
(mm)

Export diameter
(mm)

Cooling circulation external diameter
(mm)

Main rotational speed
(r/min)

Power
(Kw)

External dimension
(Long×Wide ×High)mm

Weight
(Kg)

Type

JM-WBF500-2

2-50

10-50

Ø500

Ø150

Ø80

Ø12

1450-2900

45-200

1500×650×1300

620

JM-WBF400-2

2-50

10-40

Ø400

Ø150

Ø80

Ø12

1450-2900

45-160

1400×650×1300

550

JM-WBF350-2

2-50

6-35

Ø350

Ø150

Ø80

Ø12

1450-2900

45

1400×600×1300

550

JM-WBF320-2

2-50

6-30

Ø320

Ø125

Ø80

Ø12

2900

37

1100×550×1300

500

JM-WBF320a-2

2-50

6-30

Ø320

Ø125

Ø80

Ø12

2900

45

1100×600×1300

550

JM-WBF250a-2

2-50

5-20

Ø250

Ø125

Ø60

Ø12

2900

30

1100×450×1300

400

JM-WBF250b -2

2-50

5-20

Ø250

Ø125

Ø60

Ø12

2900

37

1100×450×1300

425

JM-WBF200a -2

2-50

5-10

Ø200

Ø100

Ø50

Ø12

2900

15

750×450×1250

235

JM-WBF200b -2

2-50

2-10

Ø200

Ø100

Ø50

Ø12

2900

22

750×450×1250

250

JM-WBF200c -2

2-50

2-12

Ø200

Ø100

Ø50

Ø12

2900

30

750×450×1250

310

JM-WBF180a -2

2-50

2-6

Ø180

Ø90

Ø40

Ø12

2900

11

1000×450×1250

215

JM-WBF180b -2

2-50

2-6

Ø180

Ø90

Ø40

Ø12

2900

15

1000×450×1250

240

JM-WBF180c -2

2-50

2-8

Ø180

Ø90

Ø40

Ø12

2900

22

1000×450×1250

258

JM-WBF140a -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

7.5

780×370×1200

187

JM-WBF140b -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

11

780×370×1200

192

JM-WBF140c -2

2-50

1-4

Ø140

Ø66

Ø32

Ø12

2900

15

780×370×1200

225

JM-WBF130 -2

2-50

0.7-3

Ø130

Ø65

Ø30

Ø12

2900

7.5

750×360×1170

180

JM-WBF120 -2

2-50

0.7-2.5

Ø120

Ø65

Ø30

Ø12

2900

5.5

750×360×1150

170

JM-WBF100 -2

2-50

0.5-2

Ø100

Ø65

Ø30

Ø12

2900

5.5

740×350×1150

158

JM-WBF90 -2

2-50

0.5-1.5

Ø80

Ø47

Ø20

Ø12

2900

4

730×380×1100

110

JM-WBF80 -2

2-50

0.5-1

Ø80

Ø47

Ø20

Ø12

2900

4

730×380×1100

102

JM-WBf65 -2

2-50

0.2-0.5

Ø65

Ø47

Ø20

Ø8

2900

2.2

700×350×980

95

Special precautions:

  • Processing materials will never allow mixed with quartz sand, broken glass, metal shavings and other hard material, is prohibited to enter Jiaobenmo processing.
  • Start to close and boot cleaning before and after Jiaobenmo machine must be left in water or liquid materials, and to prohibit idling reversed. Otherwise, the operation of misconduct will be severely damaged hard disc-mechanical components or static, dynamic Disc or leaked, such as burning motor fault.
  • Products do not affect the basic structure and performance improvement, without notice. Counterfeit versions of patented products and accountability (2004 version)
